SS0607HM Mobile Lift Platform Working Height 7.9m ISO Certification

Name: SS0607HM Mobile Lift Platform Working Height 79m ISO Certification
Brand: JESH
Price: 1 USD

SS0607HM Mobile Lift Platform Working Height 7.9m ISO Certification Manufactures

Brand Name : JESH

Model Number : SS0607HM

Certification : CE/ISO

Place of Origin : CHINA

MOQ : 1 Unit

Price : Negotiation

Payment Terms : L/C, T/T

Supply Ability : 4000 Unit per month

Delivery Time : 15-30 days

Packaging Details : Regular factory packing

Working height : 6.6m

Platform : 4.6m

Platform Capacity : 230kg

Width : 0.76m

Drive Speed : 4 km/h

Battery : 24V/225Ah

Weight : 1500kg

Wheelbase : 1.32m

Contact Now

SS0607HM Mobile Lift Platform Working Height 7.9m ISO Certification

JESH self-propelled scissor lift covers working height from 6m-15m , which is suitable for indoor or outdoor use on solid flat ground. The product is compact in structure and flexible to operate. Equipped with perfect security sensor, it delivers lower noise, superb operability, which is ideal for narrow working conditions requesting higher flexibility. To strenthen design, high strength steel is used for key structures.

Technical Parameters

Dimensional Data
Model	SS0607HM
working height	7.9m
Platform Height	5.9m
Machine Width	0.74m
Machine height(Railing unfolded)	2.18m
Machine height(Railing folded)	1.8m
Platform Height/Width	1.63*0.74m
Platform Extension Length	0.9m
Ground Clearance(stowed)	0.07m
Wheelbase	1.32m
Model	SS0607HM
Platform Capacity	230kg
Platform Capacity-Extension	100kg
Maximum Workers Number	2
Turning Radius(inside/outside)	0/1.5m
Dirive Speed(Platform Lowered)	4km/h
Drive Speed (Plateform Elevated)	0.8km/h
Lift/Lower Time	16/26 sec
Gradeability	25%
Maximun Working Slope	3°
Tire Size	32.3*10m
Batteries	24V/225Ah
Features
Machine weight	1500g
Hydraulic tank capacity	15L
